PT45 HD Dual Deep Well Monitoring System with Motorized Cable Wheel
- The complete system including the mini 45mm Dual camera head,the motorized cable wheel and the surface control unit
- One pcs wooden case and dimension as:(L)83CM*(W)65CM*(H)88CM;
- Gross weight:131KG,200M;151KG,300M;171KG,400M;191KG,400M.
PT45 HD Dual Deep Well Monitoring System D10015APT-Dual with Motorized Cable Wheel
Application:
- Borehole inspection
- Deep well inspection
- Under water monitoring
- Under fresh water inspection
- All other visual applications
| HD PT45 Dual Video Head | |
| Camera Dimension | Ø45mm Dual;side 360°rotation lens and down lens |
| Sensor | 1/3" CMOS sensor |
| Resolution | 1.3MP HD |
| Rotation | Size lens:Pan:360° |
| Foucus | Mannual focus,when the head touch the deep well wall,it still can catch an clear image.(MF+/MF-) |
| View Angle | 120° |
| Waterproof | IP68,fresh water depth:50Bar(500M) |
| Illumination | Each lens with built-in 6pcs led lights and dimless |
| Lens Windows | Sapphire glass |
| Camera Housing | Stainless steel |
| Total Weight | 2.4KG |
| 13Inch Orange/Black Surface Control Unit | |
| Screen | 13inch IPS HD screen with visor |
| DVR | HD DVR video and audio recording |
| 2 pcs Joysticks | 1PC for camera head movement,1PC for manual focus |
| Video Format | MP4 |
| Menu Languages | 9 Languages optional |
| USB Tooth Keyboard | Text recording |
| Digital Meter-counter | On-screen distance |
| Temperature | On-screen |
| Direction | On-screen |
| Winch Operation Knob | Adjusting the speed,up and down the cable,brake. |
| Digital Zoom | In/out keys |
| Power Supply | Built-in 10500mA rechargeable li-ion battery pack.Run time: 5 hours |
| Battery Level Indication | Yes |
| Charger | AC110V-240V 1.5A .Charging time: 8 hours |
| Built-in Wifi Transmitter | |
| How to Work | Use the intelligent terminals as display and recording device |
| Transmitter Distance | 30M |
| Terminals | Through WIFI wireless transmit video to Adroid,AppleOS or MID terninals |
| Remote Control | Non-interference 2.4G wireless remote control |
| Handle Push Cable Wheel | |
| Material | Kevlar |
| Cable Diamter | Ø8MM thick |
| Cable Length | 100M-500M |
| Wirring Arranging Device | When the cable length 300M and above,there is must with automatic wiring arrange device. |
| Cable Wheel | Motorized |
| Winding Speed | 0-20M/Min |
| Digital Meter-counter | On-screen |
| Power Supply | AC110V-AC230V;DC12V-24V |
| Centering Skid | |
| Adjustable | Yes |
| Diameter Max | Ø420MM |
| Material | Stainless steel |
Packing Pictures:
